| Specification | Details |
|---|---|
| Model | MX204-HW-BASE |
| Form Factor | 1U fixed platform |
| Port Configuration | 4 × 100GbE QSFP28, 8 × 10GbE SFP+ |
| Uplink Options | 100GbE QSFP28 (supports breakout to 4 × 10G or 4 × 25G where licensed and supported) |
| System Throughput | Up to approximately 400 Gbps |
| Airflow | Front-to-back (model-dependent; confirm specific build) |
| Power Options | Supports redundant, hot-swappable AC or DC power supplies (depending on configuration) |
| Redundancy | Redundant PSUs and fans available depending on build; integrated Routing Engine |
| Typical Roles | Service provider edge, metro aggregation, enterprise WAN edge, Internet edge, DCI |
| Software | Junos OS |
The MX204-HW-BASE offers high throughput, multiple interface support, advanced security, and a compact form factor, making it ideal for demanding network environments.
The MX204-HW-BASE delivers up to 400 Gbps of full-duplex throughput, enabling line-rate performance across all Juniper MX204 ports. This makes it well-suited for edge routing and high-capacity aggregation deployments in both service provider and enterprise environments.
It supports 4 × 100GbE QSFP28 ports and 8 × 10GbE SFP+ ports. These interfaces allow flexible deployment across various high-speed network architectures, including core, edge, and metro use cases.
Yes, the MX204-HW-BASE supports dual hot-swappable power supply units with both AC and DC options. This ensures operational continuity and hardware-level redundancy in mission-critical environments.
The MX204 Juniper router has a 1U rack-mountable form factor with front-to-back airflow, optimized for space-constrained data center or telco rack installations. It weighs approximately 23.15 lbs (10.5 kg).
Running on Junos OS, the MX204 supports Layer 3 routing, MPLS, VPNs, and advanced security features like IPSec and DDoS protection. Licensing options such as MX204-IR, MX204-A, and MX204-LIC-ADV enable a range of capabilities depending on operational needs.
Yes, it is built for large enterprises and service providers, offering the scalability, interface density, and reliability needed for high-traffic environments. Its carrier-grade build and rich feature set make it ideal for edge, core, or peering roles.
The router is managed through Juniper’s Junos OS, which provides a consistent CLI, automation capabilities, and support for tools like NETCONF, REST APIs, and Juniper’s network management platforms. This allows for streamlined operations and configuration across deployments.
As of the latest information available, the MX204 is not officially End-of-Life (EOL) and continues to be supported by Juniper Networks.
The MX204 supports a wide range of QSFP28 and SFP+ transceivers, including 10G, 40G, and 100G optics. Compatibility includes Juniper-branded and select third-party modules, depending on firmware and license support.
MX204 routing refers to the router’s ability to support high-performance Layer 3 routing protocols, including OSPF, BGP, and IS-IS, with full support for IPv4 and IPv6. The device also enables advanced routing services such as segment routing and traffic engineering when licensed.
The MX204 delivers 400 Gbps full-duplex throughput and line-rate performance on all ports. It features a powerful packet forwarding engine and supports advanced features such as in-service software upgrades (ISSU) and non-stop forwarding (NSF) for minimal downtime.
The MX204 can support up to 4 million IPv4 and IPv6 routes, depending on the Juniper mx204 license software features and configuration. This makes it capable of handling full internet routing tables in high-scale environments.
The default login credentials are typically username: root with no password, prompting users to set one during the initial setup. For security, it’s strongly recommended to create an admin account and disable root login after configuration.
The console port on the MX204 defaults to a baud rate of 9600 bps, 8 data bits, no parity, 1 stop bit (8N1). This is a standard setting for out-of-band management via the RJ-45 console interface.
